SI 40 C 2RS

Designation: SI 40 C 2RS
Brand: YLH
Type: Rod End
Material: stainless steel
Measurement system: Metric
Thread: Female
Thread Direction: Right-Hand
Seal Type: Double-Lip Seals
Bore Dia/D: 40 mm
d1: 45 mm
Diameter Head/d2: 92 mm
Thread Thickness/d3: M 39×3
Diameter Shank/d4: 52 mm
Bottom Dia/d5: 65 mm
Raceway Diameter Inner Ring/dk: 53 mm
Width Inner Ring/B: 28 mm
Width Head/C1: 23 mm
D: 62 mm
Height Shank End Face/h1: 142 mm
Width Base/W: 55 mm
Length Threat/l3: 67 mm
Length (Height) Housing/l4: 188 mm
Bottom Thickness/l5: 18 mm
Size Wrench/l7: 48 mm
Degree: 7°
Distance from edges/r1smin: 0.6 mm
Dinamyc Ratings load/C: 263 kN
Static Ratings load/C0: 184 kN
RoHS: Compliant
REACH: Compliant
